Trench MOS

Part Number	Download	Circuit	Status	Type	Process	ESD Yes/No	VDS V	VGS V	ID A	VGS(TH) V	RDS(mΩ)@VGS 10V Typ	RDS(mΩ)@VGS 10V Max	RDS(mΩ)@VGS 4.5V Typ	RDS(mΩ)@VGS 4.5V Max	Package
Reset Reset All			Active OK Reset	Dual-N Dual-P N/P-ch Single-N Single-P OK Reset	Trench OK Reset	No Yes OK Reset	OK Reset	±10 ±12 ±16 ±20 ±25 ±30 ±6 ±7 ±8 OK Reset	OK Reset	-0.35~-1.1 -0.3~-1.0 -0.45~ -0.45~-1.0 -0.45~-1.2 -0.4~-0.9 -0.4~-1.0 -0.4~-1.2 -0.4~-1.3 -0.4·-1.0 -0.55~-1.0 -0.5~-0.9 -0.5~-1.0 -0.5~-1.5 -0.6~-1.4 -0.6~-1.5 -0.7~-1.3 -0.9~-2.0 -1.0~-2.0 -1.0~-2.5 -1.0~-3.0 -1.0~2.5 -1.1~-2.2 -1.2~-2.2 -1.5~-2.5 -1.5~-3.5 -2.0~-4.0 0.35~1.1 0.35~1.4 0.35~2.5 0.3~1.1 0.45~1.0 0.45~1.1 0.45~1.2 0.4~1.0 0.4~1.1 0.4~1.2 0.4~1.4 0.5~0.9 0.5~1.0 0.5~1.1 0.5~1.2 0.5~1.3 0.5~1.5 0.5~2.0 0.65~1.2 0.6~1.0 0.6~1.2 0.6~1.4 0.6~1.5 0.7~1.4 0.7~1.5 0.7~3.0 0.8~1.5 0.8~3.0 0.9~1.5 1.0~2.0 1.0~2.2 1.0~2.5 1.0~3.0 1.2~2.5 1.2~2.8 1.2~3.0 1.3~2.3 1.3~2.5 1.5~2.5 2.0~4.0 OK Reset	OK Reset	OK Reset	OK Reset	OK Reset	CSPB1111-4 CSPB1212-4 CSPB1313-4 CSPB1515-4 CSPB1717-4 CSPB1912-6 CSPB2217-6 CSPC2019-10 CSPC2115-10 CSPC2623-10 CSPC2624-10 CSPC3015-10 CSPC3028-14 CSPC3030-14 CSPC3220-10 CSPC3421-10 DFN1006-3L DFN1006-3L-A DFNWB2x2-6L DFNWB2x3-6L DFNWB3x3-8L DFNWB5x2-6L PDFNWB3.3x3.3-8L PDFNWB3.3x3.3-8L-B PDFNWB5x6-8L PDFNWB5x6-8L-A SOP8 SOT-223 SOT-23 SOT-23-3L SOT-23-6L SOT-323 SOT-363 SOT-523 SOT-563 SOT-723 SOT-89-3L TO-220-3L-C TO-252-2L TO-92 TSSOP8 WBFBP-03E OK Reset

CJQ4824			Active	Dual-N	Trench	No	30	±20	10	0.7~3.0	10.5	15	14.5	20	SOP8
CJQ4822			Active	Dual-N	Trench	No	30	±20	8.5	1.0~3.0	11	16	13	26	SOP8
CJ4612SP			Active	Dual-N	Trench	Yes	22	±12	6	0.5~1.3	-	-	30	36	CSPB1313-4
CJ4616SP			Active	Dual-N	Trench	Yes	15	±12	8	0.5~1.3	-	-	14	18	CSPB1515-4
UM6K1N			Active	Dual-N	Trench	Yes	30	±20	0.1	0.8~1.5	-	-	-	-	SOT-363
CJL2322			Active	Dual-N	Trench	No	20	±12	4	0.4~1.0	-	-	22	30	SOT-23-6L
CJL2311			Active	N/P-ch	Trench Trench	No No	20 -20	±12 ±8	4 -2.3	0.4~1.0 -0.4~-1.0	- -	- -	22 75	30 90	SOT-23-6L
CJL2013			Active	Dual-N	Trench	No	20	±10	6	0.5~1.0	-	-	12.2	14	SOT-23-6L
CJAC0610			Active	N/P-ch	Trench Trench	Yes Yes	100 -100	±20 ±20	10 -6.0	1.0~2.5 -1.0~-2.5	85 150	100 210	110 160	160 220	PDFNWB5x6-8L-A
CJND2004			Active	Dual-N	Trench	Yes	20	±12	10	0.4~1.0	-	-	8	10.5	DFNWB5x2-6L
CJ8218SP			Active	Dual-N	Trench	Yes	12	±8
